AISI 304L 316L 310S Stainless Steel Coil with No. 4 Finish & PVC Surface Protection
Our 2B stainless steel sheet rolls and cold rolled SS 304 coils are manufactured to the highest standards with surface treatments including 2B and hardness of 170-174 HV.
Product Specifications
| Parameter | Specification |
|---|
| Thickness | 0.1 mm - 10 mm |
| Width | 10 - 2000 mm |
| Length | 2000 mm - 6000 mm or custom |
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc. |
| Material | 201, 202, 301, 321, 304, 304L, 316, 316L, 309S, 310S, 410, 430, etc. |
| Surface | 2B, BA, 8K, No. 4, No.1 |
| Mill | TISCO, LISCO, BAO STEEL |
| Packaging | Standard export sea-worthy packing |
| Technique | Hot rolled / Cold rolled |
| Delivery Time | 7-15 days |
| Supply Ability | 3000 tons/month |
| Payment Terms | L/C, T/T |
| Application Range | Foodstuff, gas, metallurgy, biology, electronics, chemical, petroleum, boiler, nuclear energy, medical equipment, fertilizer, etc. |
Note: We can produce other standards according to customer requirements.
Material Applications
304 Stainless Steel
Architecture, decoration, chemical industry, food processing equipment, medicine, fiber industry, and automotive components.
304L Stainless Steel
Chemical, coal, petroleum, and nuclear energy industries, heat-resistant parts, and components requiring post-weld heat treatment.
Chemical Composition
| Type No. | C (%) | Mn (%) | P (%) | S (%) | Si (%) | Cr (%) | Ni (%) |
|---|
| 201 | ≤ 0.15 | 5.5-7.5 | ≤ 0.050 | ≤ 0.03 | ≤ 1.00 | 16.0-18.0 | 3.5-5.5 |
| 202 | ≤ 0.15 | 7.5-10 | ≤ 0.060 | ≤ 0.03 | ≤ 1.00 | 17.0-19.0 | 4.0-6.0 |
| 301 | ≤ 0.15 | ≤ 2 | ≤ 0.045 | ≤ 0.03 | ≤ 1.00 | 16.5-18.0 | 6.0-8.0 |
| 302 | ≤ 0.15 | ≤ 2 | ≤ 0.045 | ≤ 0.03 | ≤ 1.00 | 17.0-19.0 | 8.0-10.0 |
| 304 | ≤ 0.08 | ≤ 2 | ≤ 0.045 | ≤ 0.03 | ≤ 1.00 | 18.0-20.0 | 8.0-10.5 |
| 304L | ≤ 0.03 | ≤ 2 | ≤ 0.045 | ≤ 0.03 | ≤ 1.00 | 18.0-20.0 | 8.0-12.0 |
Mechanical Properties
| Type No. | Y.S σ0.2 (MPa) | T.S σb (MPa) | ELOG. δ5 (%) | Hardness HB | HRB | HV | Density (g/cm³) |
|---|
| 201 | ≥ 260 | ≥ 610 | ≥ 35 | ≤ 207 | ≤ 183 | ≤ 290 | 7.93 |
| 301 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 207 | ≤ 95 | ≤ 218 | 7.93 |
| 304 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 187 | ≤ 90 | ≤ 200 | 7.93 |
| 304L | ≥ 175 | ≥ 480 | ≥ 40 | ≤ 187 | ≤ 90 | ≤ 200 | 7.93 |
| 316 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 187 | ≤ 90 | ≤ 200 | 7.98 |
Standards Compliance
| Standard | Country | Description |
|---|
| ASTM | USA | American Society of Mechanical Engineers |
| AISI | USA | Acronym of American Iron and Steel Institute |
| JIS | Japan | Japanese Industrial Standards |
| DIN | Germany | Deutsches Institut für Normung e.V. |
| UNS | USA | Unified Numbering System |
Packaging Information
Standard export seaworthy packing with waterproof paper, metal belt pack sheet, placed on wooden pallets, then loaded into containers. Custom packaging available.
- 20 ft GP: 5.8m (L) × 2.13m (W) × 2.18m (H) - Approximately 23 MTS
- 40 ft GP: 11.8m (L) × 2.13m (W) × 2.18m (H) - Approximately 27 MTS
- 40 ft HG: 11.8m (L) × 2.13m (W) × 2.72m (H) - Approximately 27 MTS
Service Guarantee
- High quality products with competitive pricing
- Extensive industry experience
- Professional team and factory facilities
- Global export capabilities
- Third-party testing available before shipment
- Free samples provided
- Ample inventory with short delivery times
