ASTM A276 Grade 201 304 316L Stainless Steel Angle Bar
Hot rolled stainless steel angle bars available in sizes from 30×30mm to 200×200mm, manufactured to ASTM standards with various grade options including 201, 304, and 316L.
Product Specifications
- Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
- Grades Available: 201, 304, 310S, 316L, 321, 2205, etc.
- Standards: ASTM, GB, DIN
- Angle Bar Size Range: 30×30×3 - 200×200×10mm × 6m length
- Channel Bar Size Range: 50×30×3 - 200×100×10mm × 6m length
- Services: Custom cutting available
- Packaging: Waterproof paper wrapping or wooden pallets
- Brand: TSINGSHAN
Stainless Steel Angle Bar Specifications
Standard sizes and weight per meter for stainless steel angle bars:
| Size A×B (mm) |
3mm |
4mm |
5mm |
6mm |
7mm |
8mm |
9mm |
10mm |
| 20×20 | 0.894 | 1.13 | 1.38 | | | | | |
| 25×25 | 1.13 | 1.45 | 1.77 | 2.06 | | | | |
| 30×30 | 1.37 | 1.77 | 2.17 | 2.53 | | | | |
| 35×35 | 1.61 | 2.09 | 2.57 | 3.01 | | | | |
| 40×40 | 1.85 | 2.41 | 2.97 | 3.49 | | | | |
| 45×45 | 2.12 | 2.76 | 3.40 | 4.00 | | | | |
| 50×50 | 2.36 | 3.07 | 3.79 | 4.46 | 5.13 | 5.76 | 6.42 | 7.06 |
| 60×60 | | | 4.58 | 5.42 | 6.24 | 7.03 | | |
| 63×63 | | | 5.03 | 5.95 | 6.84 | 7.71 | 8.60 | 9.48 |
| 70×70 | | | 5.42 | 6.42 | 7.39 | 8.34 | 9.31 | 10.3 |
| 75×75 | | | 5.82 | 6.89 | 7.95 | 8.97 | 10.0 | 11.1 |
| 80×80 | | | | 7.37 | 8.50 | 9.61 | 10.7 | 11.8 |
| 90×90 | | | | 8.33 | 9.65 | 11.90 | 12.2 | 13.4 |
| 100×100 | | | | 9.28 | 10.8 | 12.20 | 13.6 | 15.0 |
Stainless Steel Channel Bar Specifications
Standard sizes and weight per meter for stainless steel channel bars:
| Size H×B (mm) |
3mm |
4mm |
5mm |
6mm |
7mm |
8mm |
9mm |
10mm |
12mm |
| 40×20 | 1.79 | | | | | | | | |
| 50×25 | 2.27 | | | | | | | | |
| 60×30 | 2.74 | 3.56 | 4.37 | 5.12 | | | | | |
| 70×35 | 3.23 | 4.21 | 5.17 | 6.08 | | | | | |
| 80×40 | 3.71 | 4.84 | 5.96 | 7.03 | | | | | |
| 90×45 | 4.25 | 5.55 | 6.83 | 8.05 | | | | | |
| 100×50 | 4.73 | 6.18 | 7.62 | 8.98 | 10.3 | 11.7 | 13.0 | 41.2 | |
| 120×60 | | | 9.20 | 10.9 | 12.6 | 14.2 | | | |
| 130×65 | | | 10.1 | 11.9 | 13.8 | 15.5 | 17.3 | 19.1 | |
| 140×70 | | | | 12.9 | 14.9 | 16.8 | 18.8 | 20.7 | |
| 150×75 | | | | 13.9 | 16.0 | 18.1 | 20.2 | 22.2 | 26.3 |
| 160×80 | | | | 14.8 | 17.1 | 19.3 | 21.6 | 23.8 | 28.1 |
| 180×90 | | | | 16.7 | 19.4 | 22.0 | 24.5 | 27.0 | 32.0 |
| 200×100 | | | | 18.6 | 21.6 | 24.5 | 27.4 | 30.2 | 35.8 |
Company Overview
We are a comprehensive stainless steel enterprise specializing in wholesale distribution, material processing, storage, and supply chain management. Located in Wuxi - the stainless steel trading hub, with total investment of 100 million RMB and annual sales exceeding 300 million RMB.
Manufacturing Partnerships
Established long-term cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribution partnerships for imported stainless steel plates from Sweden, North America, South Africa, Japan, and Korea.
Material Range & Processing Capabilities
- Material Grades: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205, 904L
- Specialty Series: High-temperature resistant, duplex stainless steel, super stainless steel
- Processing Equipment: Plasma cutting, coil material opening, laser cutting, 8K mirror finishing, grinding, wire drawing, film and titanium plating
- Specialized Services: Thick plate cutting (up to 150mm), custom shapes, casting parts, forging parts
Industry Applications
Our materials are widely used in machinery, chemical processing, petroleum, boiler manufacturing, heat exchangers, food machinery, beverage equipment, medical devices, and various industrial sectors.
Industrial Applications
Stainless steel angle bars and channel bars are essential structural components used across multiple industries for framework construction and support systems.
Primary Applications
- Structural Frameworks: High-voltage power transmission towers, steel bridge main beams
- Construction Equipment: Tower crane columns and booms, workshop columns and beams
- Building Structures: House beams, ship beams, industrial furnace frameworks
- Support Systems: Air conditioning mounts, solar panel support structures, window mounting systems
Our stainless steel angle bars and channel bars provide reliable structural support across construction, marine, energy, and industrial applications, ensuring durability and corrosion resistance in demanding environments.
