OFHC Copper Rod Formula: Cu - OFHC Percentage Purity: 99.95% Diameter: 50mm Length 1000mm

  • 1
  • 2
  • 3

Brand Name : TSING SHAN

Model Number : UNS10100/10200

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : 8.5-12.5 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Wooden Box

Model NO : UNS10100/10200

Transport Package : Standard Seaworthy Package or as Required

Standard : ASTM

Width : 60-1000MM

Length : 2000-12000mm

Sample : Available

Contact Now

OFHC Copper Rod Formula: Cu - OFHC Percentage Purity: 99.95% Diameter: 50mm

Product Description

High Ductility oxygen free copper for electrical equipment
Copper factory, more than 12 years manufacture experience, attained ISO9001, work on OEM and ODM projects..
1. Introduction of the Earthing copper strip tape
Pure copper strip is soft and malleable; a freshly exposed surface has a reddish-orange color. It is used as a conductor of heat and electricity, as It has excellent electrical conductivity, thermal conductivity, corrosion resistance , weather resistance and processing properties, can be welded and soldered.
2. Grade and temper for Earthing copper strip tape
Grade: Cu-ETP, JIS-C1100, ASTM-C11000, CDA110, GB- T2 ,BS-C102
Temper: O, 1/4H, 1/2H, H, EH
3. Chemical composition of Earthing copper strip tape

Cu+Ag:≥99.90
Sn :≤0.002
Zn:≤0.005
Pb:≤0.005
Ni:≤0.005
Fe:≤0.005
Sb :≤0.002
S :≤0.005
As :≤0.002
Bi:≤0.001
O:≤0.06
Impurities:≤0.1

4. Dimension and tolerance of Earthing copper strip tape
Width Thickness
≤1.0 >1.0~1.5 >1.5~2.5
Thickness tolerance / ±
Ordinary Level Ordinary Level Ordinary Level Ordinary Level Ordinary Level Ordinary Level
≤100 0.2 0.10 0.3 0.20 0.4 0.25
>100~300 0.3 0.15 0.4 0.25 0.5 0.30
>300~600 0.5 0.30 0.6 0.40 0.6 0.50
>600~1000 0.8 0.60 0.8 0.70 0.8 -
5. Mechanical properties for Earthing copper strip tape
Grade Temper Thickness /mm Tensile strength Elongation (%) Vickers hardness HV
(MPa)
T2 ,T3 M(soft) ≥0.2 ≥195 ≥30 ≤70
TU1,TU2 Y4(1/4H) 215~275 ≥25 60~90
TP1,TP2 Y2(1/2H) 245~345 ≥8 80~110
Y(H) 295~380 ≥3 90~120
T(HH) ≥350 - ≥110
6. Application of Earthing copper strip tape
Pure copper strip is often used in related applications, like transformer, busbar, electronic assembly. Electrical appliance, connectors, tools and molds, construction, aviation, military, decoration and so on.
Oxygen Free High Quality C10200 Copper Sheet for Capacitor
Product Description
Item C10200 Copper plate /Copper sheet/Copper Rod

Standard		 ASTM B152/B152M, EN, DIN, etc
Material C10100, C10200, C11000, C12000, C12200, C16200, C14500, C16500, C17200, C17300, C17500, C17510, C18000, C18150, C18200, C19140, C19160;
C23000, C23400, C26000, C27000, C27200, C27400;
C31400, C31600, C34500, C35300, C35330, C36000, C38000;
C46200, C46400, C48200, C48500;
C51000, C52400, C52100, C53400, C54400;
C61000, C61300, C61400, C61800, C62300, C62400, C62500, C63000, C63020, C63200, C63400, C63600, C64200, C64700,C65100, C65300, C65500, C65610, C65620, C66100, 67300, C66800, C67300, C67310, C67400, C67410, C67420, C67500, C67600, C69300, C69400, C69430;
C70600, C71500, C75200, C79200, C79300, etc
Size
Thickness:0.1mm~500mm
Width:4mm~2500mm
Length:1m~12m or as required.

Hardness
1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2hard, full hard, soft, etc

Surface
Mill, Polished, Bright, Oiled, Hair line, Brush, Mirror, Sand blast, or as required
Payment T/T, L/C, Western Union, Paypal, etc
Price term FOB, CIF, CFR, etc
Package Standard export package, or as required.
Application 1) Kitchenware, food and chemical products processing and storage devices;
2) Aircraft fuel tanks, oil pipe, rivets, wire;
3) Cans cover, car body panels, steering plates, stiffeners, brackets and other components;
4) Manufacturing trucks, tower building, ship, train, furniture, machinery parts, precision machining with the tubes, rods, shaped, sheet metal.
Detailed Description

Copper Sheet, made of pure copper or copper alloy in various shapes including rods,wires, plates, strips,tubes, foils,ect.,collectively referred to as copper.
Copper materials include copper plates, copper rods,copper tubes,copper strips,copper wires,copper bars,copper materials.
C10200 pure copper plate, as a high-purity copper material, is widely used in the power industry. It has excellent conductivity and thermal conductivity, which can meet the requirements of high pressure and high temperature. Therefore, it is widely used in the field of power equipment manufacturing.

Product Application
OFHC Copper Rod Formula: Cu - OFHC Percentage Purity: 99.95% Diameter: 50mm Length 1000mm
Application scenarios copper sheets:
1) Kitchenware, food and chemical products processing and storage devices;
2) Aircraft fuel tanks, oil pipe, rivets, wire;
3) Cans cover, car body panels, steering plates, stiffeners, brackets and other components;
4) Manufacturing trucks, tower building, ship, train, furniture, machinery parts, precision machining with the tubes, rods, shaped, sheet metal.
Packaging & Shipping

OFHC Copper Rod Formula: Cu - OFHC Percentage Purity: 99.95% Diameter: 50mm Length 1000mmOFHC Copper Rod Formula: Cu - OFHC Percentage Purity: 99.95% Diameter: 50mm Length 1000mmOFHC Copper Rod Formula: Cu - OFHC Percentage Purity: 99.95% Diameter: 50mm Length 1000mm

FAQ
Q:Are you Manufacturer or Trading company?
A: We are both manufacturer and trade in wuxi city, jiangsu Province, China.

Q:What's your main products?
A: Our main products is including Copper Plate Rod Coil Pipe

Q: Can I have free sample before making orders?
A: Yes,we can supply free sample as requirement,but buyer needs to pay the freight charges ,the freight fee will return to buyer after making order.

Q: How to visit your company?
A:By flight to WUXI International airport,then we will pick you up.

Q:Why choose us?
We have full stock, and can deliver within short time. Many styles for your choices. OEM and ODM order are accepted, Any kind of logo printing or design are available.

Q:What do your factory do regarding quality control?
We will provide formal mtc documents, if you like, when the product is ready, welcome to arrange SGS department inspect the goods,or you can come and checking the goods directly. From material to products, we inspect each process to keep good quality.
